“Here is the exceptional condition Yamaha TX816 that has been serviced recently. You won’t find anything similar to this. Every single module and chassis were restored thoroughly. Please, review photos for proofs and confirmation.

Service list:

Original power supply (early digital SMPSU) was removed. Two PSUs installed instead. Modern SMPSU is driving 5V digital line, while a massive linear PSU is for the analog +/-15V rails. This guarantees the best of both worlds , no noise and power ripple. There is no off-the-shelf PSU that can easily replace the original. You have to make a custom design. This one is the best. Keep in mind, the system is configured to 120V AC.
There is also AC filter board inside, it has been serviced as well and film caps replaced. Those are known to make a smoke.
Chassis backplane and all connectors on it has been re-soldered. Those are known for cracks especially if you often push modules in and out.
Every single module was recapped. All electrolytic caps were replaced with genue Nichicon FG series (Fine Gold and MUSE audio series).
All audio relays (8 total) have been replaced. This is your source for intermittent sound when failed.
Old batteries there removed, every module got a CR2032 battery holder and new battery. No more soldering if you need to replace it in 10 years.

All modules have been preloaded with a factory data. This is an unique patch set where all 8 modules are engaged for the total of 48OP synthesis. (each module is loaded with own bank). This is more than a simple layering that you may think of. This is a mind blowing how great those patches are.

This TX816 is made to work 24×7. Make your music. I’ll take of repair. And check my other items. ” Click here to visit listing on eBay
